Welding Guide: Choosing the Correct Weld-In Bungs

Choosing the right weld-in bung comes down to matching three things: the internal thread to the rod end you’re installing, the bung’s outer diameter to the tube’s actual inside diameter (not its nominal size), and the thread hand (RH or LH) to whether the finished link needs to adjust without disassembly. Get any one of those wrong and you end up with a rod end that won’t thread in, a weak or off-center weld, or a link that can’t be adjusted the way you planned.

What a Weld-In Bung Actually Is

The market uses "weld-in bung," "tube adapter," and "threaded insert" more or less interchangeably, and that’s a real source of confusion, not a distinction this article is inventing. In practice they’re the same idea: a machined steel insert, threaded internally, that you weld into (or onto) the end of a tube so a rod end, Heim joint, or clevis can thread into what was previously plain tubing. Some are stepped adapters that slide partway into the tube ID; others sit flush as a plug at the tube end. The welding and fitment principles below apply to either style.

The Three Things That Have to Match

1. Thread size and pitch, exact. The bung’s internal thread has to equal the rod end’s thread spec — e.g., 3/4-16 UNF — not "close enough." A mismatch either won’t thread at all or engages so little that it fails under load well below the rod end’s rating.
2. Bung OD to actual tube ID, not nominal tube size. Tube ID = outer diameter minus twice the wall thickness. You want the bung’s OD to be a close slip fit into that real number so the weld has full contact and self-centers during tacking. One off-road fabrication supplier’s published product line gives a sense of the scale involved — these are that one manufacturer’s specific part numbers, not a universal standard, but useful as a reference point:

1. Thread hand (RH or LH). Both ends RH gives you a fixed, non-adjustable link. One RH and one LH gives you the turnbuckle effect — adjustable by rotating the tube without disconnecting either end. That mechanism and the trade-offs around it are covered in Using LH/RH Threads for Quick Linkage Adjustments — decide which you need before you order bungs, since ordering the wrong hand means re-ordering, not an easy fix.

Welding It In Without Ruining the Rod End

Remove the rod end or Heim joint before you weld — always. This is the one point every source on this topic agrees on without exception: welding heat destroys a bearing’s heat treatment and melts any PTFE liner. Weld with the joint installed and you’ve either seized it or wrecked its load rating before it’s ever been used. If you need a joint threaded in during the weld for alignment purposes, use a cheap, dedicated "sacrificial" joint you don’t mind trashing — several fabricators run an old or bargain Heim joint with anti-seize on the threads specifically for this, then back it out once the weld is done.

1. Fit-check dry first. Confirm the bung is a close slip fit in the tube ID before you strike an arc — a sloppy fit means a weak, hard-to-penetrate weld no matter how careful your technique is.
2. Tack in at least three spots around the joint before running a full weld, to control distortion as the metal heats and cools unevenly.
3. Complete with a full-penetration weld. A partial or cosmetic weld at the tube/bung interface is a common point of failure under cyclic suspension or steering loads.
4. Let it cool completely before threading anything in. Metal expands when heated and shrinks as it cools; threading a rod end into a bung that’s still warm risks galling or seizing threads that would have fit fine once fully cooled. If you’re testing thread fit and burn yourself finding this out the hard way, you’re not the first.
5. Chase the threads with the correct tap if they’ve shrunk. Heat close to the internal threads can shrink the bore enough that a correctly sized fastener won’t thread in until you run a tap through to clear it back to spec. Keep the matching tap on hand before you start, not after you discover you need it.
6. TIG gives you more heat control than MIG or stick, if you have the option. The tighter you can control amperage and heat concentration, the less risk of shrinking threads or blowing through thin-wall tubing. If MIG is what you have, a stacked-tack approach — overlapping short tacks with brief pauses between them — limits how much heat builds up in one spot compared to a continuous bead. Exact amperage depends heavily on your specific tube wall thickness and bung mass; there’s no single number that applies across different tube gauges, so treat any amperage figure you find for a different application (thin sheet metal, for instance) as a starting reference, not a spec to copy directly.

Common Failure Modes

Worked Example

Building an adjustable link around a 3/4-16 UNF male rod end, using 1.5" OD × 0.120" wall DOM tube:

1. Bung internal thread = 3/4-16 UNF, matching the rod end.
2. Tube ID = 1.5" − (2 × 0.120") = 1.26" — pick a bung whose OD is a close slip fit to that number.
3. Thread hand: one RH bung and one LH bung if the link needs to adjust by rotation; both RH if it’s a fixed-length link.
4. Weld per the steps above, cool completely, then thread the rod end in and jam-nut it once the length is set.

The numbers change with your specific rod end and tubing; the sequence of matching thread → matching tube ID → deciding thread hand → welding correctly stays the same regardless of size.

If you’d rather source ready-made adapters instead of machining and matching bungs yourself, SYZ Machine’s Tube Adapters & Weld Bungs line covers chromoly weld-in adapters, bung adjuster nuts, and linkage adjusters in both RH and LH, inch and metric — useful as a reference for what’s commercially available even if you end up fabricating your own.

Related reading: Using LH/RH Threads for Quick Linkage Adjustments · How to Inspect for "Binding" After Installation
